Thanks to our underfloor distributors, electrical power is quickly available anywhere and without time-consuming installation work! Tailored, customized equipment according to choice.
As with all our products, we attach tremendous importance to using high-quality components and production techniques.
One material plays a vital role for GIFAS products: solid rubber made from butyl rubber. This elastomer possesses numerous properties that make it the ideal material for hard-working products. These properties include, for example, the excellent attenuation of oscillation and impact energy, the strong resistance to acids and bases, excellent resistance to weather, UV and ozone and a high electrical insulating capacity.
Further product properties of mobile distributors:
- All external metal parts made from rust-proof material
- Solid rubber sockets with nickel-plated contact sleeves
- Fuse elements protected with special shock-resistant cover
- SS screws set in rust-proof brass press-fit bushings with dual anchor
- Wired ready for connection
- Parts can be exchange individually
- Protection category up to IP 65
- Self-extinguishing and flame-resistant
- Comply with all minimum standards requirements for equipment of Category 2 “K2”
Dimensions: 250 x 360 x 132mm
Weight: 5-8kg
Protection Category: IP54
| Item no. | Symbols Output | Output | Input | Cable/personal protection |
|---|---|---|---|---|
| Assembly Variants |          |
|||
| 291353 | | 1 CEE 5x16A/400V | 3m 5x2.5mm2 CEE 5x16A/400V | PRCD-S 400V/16A |
| 291351 | | 1 CEE 5x32A/400V | 3m 5x6mm2 CEE 5x32A/400V | PRCD-S 400V/32A |
