Special Features
- Tyre load: 6 t (20 x 20 cm)
- Securely locked
- Slip resistant, abrasion-resistant
- Temperature resistant, not weather sensitive
- Solvent, petrol, oil and road salt resistant
The MEGA was developed for major events. The main features of this heavy-load protector are its oversized cable / hose channels for cables of up to 120 mm (e.g. 2 x A hose), shatter-proof connectors and plug housing not >= 100 mm. When used in public traffic situations, please be aware of road traffic acts that are pertinent to your country.
Technical Data
| Technical Data | |
|---|---|
| Material in lower section | black polyurethane |
| Material in upper section | yellow polyurethane |
| Fire safety class | B2 (compliant with DIN 4102) |
| Working range | -30°C to +60°C |
| Hardness range | 88 Shore ± 4A. |
| Max. load | approx. 5t/ 400 mm2 |
| Dimensions (LxWxH) | 700x783x139mm |
| Channels | 2+2 |
| Channel width | 35mm35mm, 120mm, 120mm, 35mm |
| Channel height | 50mm, 115mm, 115mm, 50mm |
| Weight | 30.5kg |
Product Range
| Item no. | Description |
|---|---|
| 256985 | MEGA 4-channel cable protector |
